Frequency converter
FC-103N132T4E54H4TGC3XXSXXXXA0BXCXXXXDX
VLT® Refrigeration Drive FC-103
(N132) 132 KW / 200 HP,
Three phase, 380 – 480 VAC,(E54) IP54 / Type 12
RFI filter Class A1
Safe Stop
Graphical Loc. Cont. Panel
Coated PCB, Mains Disconnect + Fuse
Latest release std. SW.
PROFIBUS DP MCA 101, No B Option
No C1 option, No D option
Frame: D5H
Other options according to Model code
Model code:
FC-103N132T4E54H4TGC3XXSXXXXA0BXCXXXXDX
Whether you want to operate compressors, pumps or fans, the VLT®Refrigeration Drive FC 103 gives you the opportunity to save energy andextend the lifetime of the components.
| Gross weight | 166.3 Kilogram | ||
| Net weight | 166 Kilogram | ||
| EAN | 5715253780863 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® Refrigeration Drive | |
| Series | 103 | 103 | |
| Power Rating | N132 | (N132) 132 KW / 200 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 4 | 380 – 480 VAC | |
| Enclosure | E54 | (E54) IP54 / Type 12 | |
| RFI Filter | H4 | RFI filter Class A1 | |
| Brake – Safe Stop | T | Safe Stop | |
| LCP | G | Graphical Loc. Cont. Panel | |
| Coating PCB | C | Coated PCB | |
| Mains Option | 3 | Mains Disconnect + Fuse | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | A0 | PROFIBUS DP MCA 101 | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | D5H | D5H | |
| Product Catalog | NO_VIEW | NO VIEW | |
| Typecode Part 1 | FC-103N132T4E54H4TGC | ||
| Typecode Part 2 | 3XXSXXXXA0BXCXXXXDX | ||
| Power 110% (NO) [KW] | 132 | 132 | |
| Height [mm] | 1324,0 | 1324,0 | |
| Width w/ no C options [mm] | 325,0 | 325,0 | |
| Depth [mm] | 381,0 | 381,0 | |
| Depth with Option A/B [mm] | 381,0 | 381,0 | |
| kVA | 180 | 180 | |
| Power Loss NO [W] | 2949 | 2949 | |
| Power Loss NO [W] | 2719 | 2719 | |
| Continuous Current (NO) [A] | 260 | 260 | |
| Intermittent Current (NO) [A] | 286 | 286 | |
| Continuous Current (NO) [A] | 240 | 240 | |
| Intermittent Current (NO) [A] | 264 | 264 | |
| Calculated Gross Weight [kg] | 166.3 | ||
| Calculated Net Weight [kg] | 166 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Plant from Orderline | D801 | D801 | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Modelcode01 | FC-103N132T4E54H4TGC | ||
| Modelcode02 | 3XXSXXXXA0BXCXXXXDX |
